A-50+ Multifunctional Optical Fiber Identifer & Optical Power Meter
Price in Bangladesh
The lowest price of A-50+ multifunctional optical fiber identifer & optical power meter in Bangladesh is Tk 8,500 only. Buy A-50+ at low price in Bdstall. There is currently 1 seller.
01930890110
1 day ago
6 months parts
1 year service
NewFull Specification
| Item | Networking Accessories |
|---|---|
| Model | ✅ A-50+ |
- General Information
- Item Type: Optical Fiber Identifier
- Application: Fiber optic identification
- Battery: lithium battery 3.7V 650mAh shipped with a built-in battery
- Physical
- Build Material: ABS
- Basic Parameters
- Wavelength Range: 800 to 1700nm
- Recognition Type: CW, 270Hz ± 5%, 1kHz ± 5%, 2kHz ± 5%
- Detector Type: Dia. Approx. 1mm / 0.04in InGaAs (2 pcs)
- Adapted Fiber Type
- Universal dia. 0.25, dia. 0.9 for bare fibers, dia. 2.0, dia. 3.0 for tail fiber
- Direction: LED indicator light for left and right direction indication
- Optical Power Reading Range: -50dBm to +26dBm
- Display Resolution Linear Display: 0.1%
- Logarithmic Display: 0.01dBm
- Optical Power Meter Wavelength Range: 850 to 1650nm
- Use Distance of the Red Light Source: Greater than Approx. 10000m / 32808.4ft
- Temperature
- Working Temperature: -10 to +60 °C
- Storage Temperature: -25 to +70 °C
- Package List
- 1 x Optical Fiber Identifier
- 1 x Manual
- 1 x USB Cable
- 1 x Storage Box
Description
A-50+ is a multifunctional optical fiber identifier. It is used for fiber optic identification. It features a 650mAh lithium battery and is built from ABS material. The A-50+ fiber identifier operates within a wavelength range of 800 to 1700nm, with recognition types of CW and modulated signals at 270Hz, 1kHz & 2kHz. It adapts various fiber types, including diameters of 0.25mm, 0.9mm for bare fibers, and up to 3.0mm for tail fibers. It also can reads from -50dBm to +26dBm, with display resolutions of 0.1% for linear and 0.01dBm for logarithmic readings.
