Ahuja PMX-1032DFX 48V 10-Channel Mixer
ID:
147255
Status: In Stock
)
Price in Bangladesh
The lowest price of Ahuja pmx-1032dfx 48v 10-channel mixer in Bangladesh is Tk 35,000 only. Buy PMX-1032DFX from Dhaka at low price in Bdstall. There is currently 1 seller.
01711651397
2 days ago
NewFull Specification
| Item | Audio Interface |
|---|---|
| Model | ✅ PMX-1032DFX |
- Mic Input
- Impedance/Gain: 2kΩ Balanced/65dB
- Line Input
- Impedance/Gain: 20kΩ Balanced/45dB
- STEREO INPUT (L/Mono & R)
- Impedance/Gain (-10dBu Input): 10kΩ Balanced/14dB
- Impedance/Gain (+4dBu Input): 10kΩ Balanced/0dB
- THD <0>
- Frequency Response: 25Hz–20kHz (+0, -1dB)
- EQUALIZATION
- Bass/Mid/Treble: ±12dB at 100Hz/2kHz/10kHz
- Clip LED Indication: 4 dB before true clip
- Line Output
- Nominal/Max Level 4dBu/21dBu (1.22V/9V)
- Impedance: 600Ω
- Delay System: Digital Signal Processing
- Delay RANGE Settings: 1: 60-300 ms; 2: 300-500 ms; 3: 500-650 ms Variable from 20 to 300 ms
- Digital Player: MP3 Player with USB, SD, and MMC Card Reader
- Headphone Output 200mV at 8Ω, THD <1>
- Maximum Gain
- Mic Input to Line Outputs: 78dB
- Line Input to Line Outputs: 58dB
- Stereo Input to Line Outputs: 28dB (-10dBu Input) 14dB (+4dBu Input)
- AUX Send (Pre): 1.4V/100Ω Unbalanced
- AUX Send (Post): 2.7V/100Ω Unbalanced
- AUX Return (L&R): 150mV/10kΩ Balanced
- Record Output (L&R): 250mV/600Ω
- Playback Input (L&R): 250 mV/1 kΩ (variable through GAIN control)
- Signal-To-Noise Ratio: 70dB
- Power Supply AC: 220-240V, 50Hz
- Dimension: W465 x H110 x D435 mm
- WEIGHT 7.70kg
Description
This Ahuja PMX-1032DFX is a 48V 10-channel mixer that comes with a separate EFFECT channel, which is included to control the built-in digital effect processor through delay, repeat, and level controls. Also, all the Line & Stereo inputs are through 6.3mm stereo phone jack sockets, and the MIC inputs are through 3-pin F/XLR connectors.
