Asrock H610M-H2/M.2 mATX DDR4 Motherboard
)
)
)
Price in Bangladesh
The lowest price of Asrock h610m-h2/m.2 matx ddr4 motherboard in Bangladesh is Tk 9,800 only. Buy Asrock H610M-H2/M.2 from Dhaka at low price in Bdstall. There is currently 1 seller.
01925437248
moment ago
3 years parts
3 years service
NewFull Specification
| Item | Motherboard |
|---|---|
| Model | ✅ Asrock H610M-H2/M.2 |
| Motherboard Type | Standard |
| Chipset | Intel H610 |
| Supported Processors | 12th, 13th & 14th Processors |
| Max Memory | 64GB |
| Onboard Audio | 7.1 CH HD Audio with Realtek ALC897 Audio Codec |
| Onboard LAN | Gigabit LAN 10/100/1000 Mb/s, Realtek 8111H |
- CPU
- Supports Intel Hybrid Technology
- Supports Intel Turbo Boost Max 3.0 Technology
- BIOS: 128Mb AMI UEFI Legal BIOS with GUI support
- Micro ATX Form Factor: 8.66-in x 7.6-in, 22.0 cm x 19.3 cm
- Expansion Slot
- PCI: 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode
- Chipset: 1 x PCIe 3.0 x1 Slot (PCIE2)
- M.2 Socket: 1 x Ultra M.2 Socket (M21, Key M), supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) mode
- Memory
- Type: Dual Channel DDR4 Memory Technology
- Slots: 2 x DDR4 DIMM Slots
- Supported Memory
- Supports DDR4 non-ECC, un-buffered memory up to 3200
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Supports Intel Extreme Memory Profile (XMP) 2.0
- Graphics
- Intel Xe Graphics Architecture (Gen 12)
- 2 x HDMI 2.1 TMDS Compatible
- HDCP 2.3 and max resolution up to 4K 60Hz
- Intel UHD graphics, built-in visuals, and the VGA outputs can be supported only with processors that are GPU integrated
- Connectors & Ports
- 2 x HDMI
- 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front)
- 6 x USB 2.0 (4 Rear, 2 Front)
- 4 x SATA3 6.0 Gb/s
- I / O Ports
- 1 x SPI TPM Header
- 1 x Chassis Intrusion and Speaker Header
- 1 x CPU Fan Connector (4-pin)
- 1 x Chassis/Water Pump Fan Connector (4-pin)
- 1 x 24-pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
- Bundled Software
- ASRock Motherboard Utility (A-Tuning) UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Auto Driver Installer
- ASRock Instant Flash
Description
The ASRock H610M-H2/M.2 is a powerful motherboard that comes with 3.0 turbo boost technology that ensures your daily working smoothly. The motherboard supports 12th, 13th & 14th generation processors for higher performance. The motherboard also offers Intel Xe graphics, which provide a fast multitasking, working, or gaming experience. It features dual-channel DDR4 technology with 2 x DDR4 DIMM slots. The motherboard is equipped with Realtek ALC897 7.1 CH HD Audio that offers high-quality sound. Besides, it has 64GB of memory storage and an Intel H610 chipset.
