REVOLT 2kVA Hybrid Solar Inverter IPS
ID:
139575
Status: In Stock
-8%
)
)
)
)
Price in Bangladesh
The lowest price of Revolt 2kva hybrid solar inverter ips in Bangladesh is Tk 22,500 only. Buy NML-2000-12V from Dhaka at low price in Bdstall. There is currently 1 seller.
01771115656
2 days ago
1 year parts
2 years service
NewFull Specification
| Item | Solar IPS |
|---|---|
| Model | ✅ NML-2000-12V |
- Pure Sine Wave Inverter
- Configurable Solar or Grid priority
- Wide AC input voltage range (90- 280V) for stable operation
- Compatible with grid or generator
- Compatible with 12V battery system (Lead Acid / Lithium)
- Configurable battery charging current (20A-80A)
- Configurable AC/Solar charging priority
- MPPT range: 30-400V for enhanced solar efficiency
- Cold start function
- Overload / over-temperature / short-circuit protection
- AC Input
- Voltage: 230VAC
- Selectable Voltage Range
- 170-280VAC(Personal Computer)
- 90-280VAC(Home Appliances)
- Frequency Range: 50Hz/60Hz(Auto Sensing)
- AC Output
- AC Voltage Resolution: 230VAC+_5%
- Surge Power: 4000VA
- Efficiency(Peak)PV to INV: 98%
- Efficiency(Peak)Battery to INV: 94%
- Transfer Time
- 10ms(For personal computer)
- 20ms(For home appliances)
- Battery & AC Charger
- Battery Voltage: 12VDC
- Floating Charge Voltage: 13.5VDC
- Overcharge Protection: 16VDC
- Maximum AC Charge Current: 60A
- Solar Charger
- Maximum PV Array Power: 2000W
- MPPT Range at Operating Voltage: 30- 400VDC
- Maximum PV Array Open Circuit Voltage: 400VDC
- Maximum Charge Current: 80A
- Operating Environment
- Humidity: 5% to 95% Relative Humidity(Non-condensing)
- Operating Temperature: -10 to 50 degrees Celsius
- Physical
- Dimension: 357 x 273 x 95mm
- Net Weight: 4.6 Kg
- Communicating Interface: RS232
Description
The REVOLT NML-2000-12V Hybrid Solar Inverter comes with some amazing features such as Pure Sine Wave Inverter technology, configurable solar or grid priority, wide AC input voltage range (90- 280V) for stable operation, compatible with grid or generator, compatible with 12V battery system, configurable battery charging current up to 20A-80A, configurable AC/Solar charging priority, MPPT range up to 30-400V for enhanced solar efficiency, as well as overload, over-temperature, and short-circuit protection.
