Dahua IPC-HFW1230S-S5 2MP Entry IR Network Camera
ID:
91857
Status: Sold Out
)
)
)
What is the price of Dahua IPC-HFW1230S-S5 in Bangladesh
The lowest price of Dahua IPC-HFW1230S-S5 in Bangladesh is Tk 3,850 only. Buy IPC-HFW1230S-S5 at low price in Bdstall. There is currently 0 seller.
Dahua IPC-HFW1230S-S5 Full Specification
| Item | CCTV Camera |
|---|---|
| Model | ✅ IPC-HFW1230S-S5 |
| Brand | Dahua |
| CCTV Type | Fixed |
| Sensor | 1 / 2.8" CMOS |
| White Balance | Auto / Natural / Street lamp / Outdoor / Manual / Regional custom |
| Lens | 3.6mm |
| Video Resolution | 1920 x 1080p |
| Signal System | LAN |
| Day / Night | Yes |
| IR | Yes |
| Connectivity | IP Camera |
| Waterproof / Dustproof | IP67 |
| CCTV Housing | Bullet |
| Power Supply | 12V DC / PoE (802.3af) |
- Camera
- Max. Resolution: 1920 x 1080
- ROM: 16 MB
- RAM: 64 MB
- Scanning System: Progressive
- Electronic Shutter Speed: Auto / Manual 1 / 3s – 1 / 100000s
- Min. Illumination: 0.01 Lux F2.0
- S / N Ratio: >56 dB
- Illumination Distance: 30 m (98.4 ft)
- Illuminator On / Off Control: Auto / Manual
- Illuminator Number: 18 (IR LED)
- Pan / Tilt / Rotation Range:
- Pan: 0° to 360°
- Tilt: 0° to 90°
- Rotation: 0° to 360°
- Lens:
- Lens Type: Fixed-focal
- Lens Mount: M12
- Focal Length: 2.8 mm, 3.6 mm
- Max. Aperture
- 2.8 mm: F2.0
- 3.6 mm: F2.0
- Field of View
- 2.8 mm: Horizontal: 102°, Vertical: 54°, Diagonal: 120°
- 3.6 mm: Horizontal: 84°, Vertical: 45°, Diagonal: 100°
- Iris Control: Fixed
- Close Focus Distance
- 2.8 mm: 0.5 m (1.6 ft)
- 3.6 mm: 0.8 m (2.6 ft)
- DORI Distance
- Lens Detect Observe Recognize Identify
- 2.8 mm 38.6 m(126.6 ft) 15.4 m(50.5 ft) 7.7 m ( 25.3 ft) 3.9 m(12.8 ft)
- 3.6 mm 49.7 m(163.1 ft) 19.9 m(65.3 ft) 9.9 m (32.5 ft) 5.0 m(16.4 ft)
- Video
- Video Compression: H.265; H.264; H.264B; MJPEG (only supported by the substream)
- Smart Codec: Smart H.265+ / Smart H.264+
- Video Frame Rate
- Main Stream
- 1920 x 1080 (1fps–25 / 30 fps)
- Sub Stream
- 704 x 576 (1 fps–25 fps)
- 704 x 480 (1 fps–30 fps)
- Stream Capability: 2 streams
- Main Stream
- Resolution
- 1080p (1920 x 1080)
- 1.3M(1280 x 960)
- 720p (1280 x 720)
- D1 (704 x 576 / 704 x 480)
- VGA (640 x 480)
- CIF (352 x 288 / 352 x 240)
- Bit Rate Control: CBR / VBR
- Video Bit Rate
- H.264: 32 kbps–6144 kbps
- H.265: 12 kbps–6400 kbps
- Day/Night: Auto (ICR) / Color / B / W
- BLC: Yes
- HLC: Yes
- WDR: DWDR
- Gain Control: Auto / Manual
- Noise Reduction: 3D NR
- Motion Detection: OFF / ON (4 areas, rectangular)
- Region of Interest (RoI): Yes (4 areas)
- Smart Illumination: Yes
- Image Rotation: 0° / 90° / 180° / 270° (Support 90°/270° with 1080p resolution and lower)
- Mirror: Yes
- Privacy Masking: 4 areas
- Alarm Event
- Network disconnection
- IP conflict illegal access
- Motion detection
- Video tampering
- Safety exception
- Network
- Network: RJ-45 (10 / 100 Base-T)
- SDK and API: Yes
- Cyber Security
- Video encryption
- Configuration encryption
- Digest
- WSSE
- Account lockout
- Security logs
- Generation and importing of X.509 certification
- HTTPS
- Trusted boot
- Trusted execution
- Trusted upgrade
- Network Protocol:
- IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP
- SMTP, FTP, DHCP, DNS, NTP, Multicast
- Interoperability: ONVIF (Profile S / Profile T), CGI, P2P, Genetec
- User/Host: 6 (Total bandwidth: 36 M)
- Storage: FTP
- Browser: IE, Chrome, Firefox
- Management Software: Smart PSS, DSS, DMSS
- Mobile Client: IOS, Android
- Certification:
- CE-LVD: EN62368-1
- CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
- FCC: 47 CFR FCC Part 15, Subpart B
- Power Consumption
- Basic power consumption: 1.5W (12V DC), 2.3W (PoE)
- Max. power consumption (ICR + H.265+IR intensity): 4.3W (12V DC), 5.5W (PoE)
- Environment
- Operating Conditions: -40 to +60 Degree
- Storage Temperature: -40 to +60 Degrees
- Casing: Metal + plastic
- Product Dimensions: 164.6 x 70mm
Dahua IPC-HFW1230S-S5 Description
Dahua IPC-HFW1230S-S5 2.0MP is an entry IR network camera used in outdoor surveillance. It has Smart H.265+ and Smart H.264+ encoding technologies, which reduce storage and transmission costs while delivering high-quality video. This camera features motion detection technology, smart lighting for low-light environments, and image flip for better surveillance in rotation mode. It also provides key security technologies including access control, trusted protection, encrypted transmission, and encrypted storage to prevent malicious programs from accessing devices.
